Antistatic garments or antistatic clothing is required to prevent damage to electrical components or to prevent fires and explosions when working with flammable liquids and gases.

One of the ways to bond or electrically connect personnel to ground is the use of an ESD garment. ESD garments have conductive threads in them, creating a wearable version of a faraday cage. ESD garments attempt to shield ESD sensitive devices from harmful static charges from clothing such as wool, silk, and synthetic fabrics on people working with them. For these garments to work properly, they must also be connected to ground with a strap. Most ESD garments are not conductive enough to provide personal grounding so antistatic foot straps and antistatic wrist straps are also worn. ESD garments are considered an optional method to control ESD.

An ESD protected area is a defined location with the necessary materials, tools, and equipment capable of controlling static electricity to a level that minimizes damage to ESD susceptible items. In the ESD protected area, all conductors in the environment, including personnel, shall be bonded or electrically connected and attached to a known ground or contrived ground. This attachment creates an equipotential balance between all items and personnel. Electrostatic protection can be maintained at a potential above a "zero" voltage ground potential as long as all items in the system are at the same potential.

Antistatic garments are used in many industries such as electronics, communications, telecommunications and defense applications. As computers and electronics become ever more pervasive in consumer products so an increasing number of manufacturers will need to apply anti-static control measures. One such measure is antistatic apparel because people are the greatest source of static charge in the workplace.

Transportation of electrostatic sensitive devices also requires packaging that provides protection from electrostatic hazards in the transportation or storage system. In the case of an ESD protected area designed with continuous grounding of all conductors and dissipative items (including personnel), packaging may not be necessary.

The amount of static electricity we feel varies according to factors such as our body and foot size. A larger body and bigger feet require more charge to be stored to produce the same voltage. The material our clothes are made from and the soles of our shoes can influence static electricity too. Weather affects it as well. There is more build-up of static charge when the air is dry. Most people feel harmless shocks at around 2,000-4,000 volts. However electrical components can be damaged by as little as a few volts. It is estimated that between eight percent and 33 percent of product losses—-the proportion of products which are rendered faulty—-are due to static electricity. Static electricity is generally harmless to the individual but if not controlled, electrostatic discharge can cause product damage to electrostatic sensitive devices and lead to machinery downtime, lost man-hours, returned products and warranty costs particularly in the semiconductor and electronics industries, which caused 5 billion USD worth of damage to products each year.

What is the difference between fire retardant and fire resistant?

The biggest difference between flame resistant and flame retardant fabrics lies in how each is made. Without a special chemical application, a fabric will not qualify as flame retardant. Similarly, without being made of certain non flammable fibres, a fabric will not quality as fire resistant.

How do you wash FR clothing?

Home Wash
Wash separately in a Normal or Cotton cycle at any water temperature up to a maximum of 140ºF (60ºC). ...
Turn garments inside out before wash to reduce streaking from abrasion. ...
DO NOT use chlorine bleach or liquid non chlorine bleach.

What does inherently flame retardant mean?

Inherently flame resistant fibres are materials that have flame resistance built into their chemical structures. ... A chemical additive in the fibre or treatment on the fabric is used to provide some level of flame retardancy. During a fire, chemically dependent fabrics rely on a chemical reaction to extinguish the flame.

Is cotton flame resistant?

No, There is a common perception that untreated 100% cotton fabric is somehow “flame-resistant”. This is simply not true. While heavyweight untreated 100%cotton fabrics may be more difficult to ignite, they can and will ignite and continue to burn if exposed to an ignition source.

What is the definition of flame resistant?
A substance that is applied to fabric, wood, or other material in order to make it resistant to catching fire. Also called fire retardant.

Is wool resistant to fire?
Wool is an amazing fibre with so many inherent qualities that can benefit humans. It is naturally flame resistant.

AS/NZS 1906.4:2010 - High visibility materials for safety garments

This standard specifies minimum colour and luminance requirements for fluorescent (F) or non-fluorescent (NF) background (compliant) materials and retro-reflective material (reflective tape) as used in the manufacture of garments for high risk applications.

“Class F” (fluorescent background material):

Refers to Fluorescent fabrics which have fluoro pigments. These include all our Safety Vests, Polo’s, Polyester/Cotton Shirts and Rainwear. Our Fluoro Yellow and Fluoro Orange Polycotton Protex Overalls also meet “Class F”. This includes DOPPC, TTPPCLT & CTPPCLW styles.

“Class NF” (Non—fluorescent background material):

All 100% Cotton Overalls, our natural fibres CTPCNLW and FTPCNLW, the Modacrylic FEPVC and FJPVC, and the 100% cotton Shirts are “Class NF” (Non—fluorescent background material). In general, natural fibres are not capable of taking a fluorescent pigment. The main difference is Class F garments have to meet a lot higher minimum luminance level than Class NF garments.

Click Here for the Eo6 Standard

Download NZTA-E06-2023-specification-for-high-visibility-safety-garments-august-2023.pdf
